- Model: LQ121S1LG61
- Diagonal: 12,1″
- Resolution: 800×600
- Manufacturerer: SHARP
- Article no.: 8540563
LQ121S1LG61
LQ121S1LG61 Sharp LCD Display technical data
| Brand | Sharp |
| Diagonal | 12,1″ |
| Resolution | 800(RGB)×600, SVGA 82PPI |
| Brightness | 450 cd/m² (Typ.) |
| Panel Type | a-Si TFT-LCD, LCM |
| Viewing Angle | 70/70/50/60 (Typ.)(CR≥10) |
| Display Mode | TN, Normally White, Transmissive |
| Treatment | Antiglare, Hard coating (3H) |
| Interface Type | Parallel RGB (1 ch, 6-bit) , Connector 20 pins |
| Support Colors | 262K 45% NTSC |
| Pixel Format | RGB Vertical Stripe |
| Contrast Ratio | 600:1 (Typ.) (TM) |
| Backlight | CCFL [2 pcs] , 50K hours , W/O Driver |
| Max. Rating | Operating Temperature: 30 ~ 80 °C Storage Temperature: -30 ~ 80 °C Vibration Level: 1.5G (14.7 m/s²) |
LQ121S1LG61 Sharp LCD Synopsis
LQ121S1LG61 is a 12.1″ diagonal a-Si TFT-LCD display from Sharp Corporation (after that it called Sharp), it is without backlight driver and with an integral CCFL backlight system and witout touch screen. The resolution of this display is 800×600 and the brightness is about 450cd/m² . It’s general features are summarized by Tsubis GmbH in the following: The panel has a life time about 50K hours, Display Mode is Normally white and Transmissive. Based on the features, Tsubis would recommend that this model can be applied to Industrial sector. The model mass production was on Q1, 2006 and last shippment was Q3, 2011, Now this model is discontinued. If you want to plan the LQ121S1LG61 in your future project, Tsubis GmbH would like to suggest to make a contact with a Sharp or a Sharp distribute agent to learn about the alternative solution and inform about the latest production and specification detail.. The production status marked on Tsubis.com is only for reference, please don´t use it as the basis for the decision making. All specification details are according to datasheet, but we cannot guarantee for the content.
