- Model: HLM 8619 (TW-22 94V-0)
- Diagonal: 5,7″
- Resolution: 320×240
- Manufacturerer: HOSIDEN
- Article no.: 8540432
HLM 8619 (TW-22 94V-0)
HLM 8619 (TW-22 94V-0) Hosiden Display technical data
| Diagonal (Zoll) | 5,7 inch |
| Resolution | 320×240 Pixel |
| Luminance | 150cd/m² |
| Panel Type | FSTN-LCD, LCM |
| Brand | Hosiden |
| Viewing Angle | 55 (Typ.)(CR≥1.4)(θ2+θ1) |
| Response Time | 200/150 (Typ.)(Tr/Td) |
| Lamp Type | 1 pcs CCFL , 25K hours , Without Driver |
| Frame Rate | 70Hz |
| Support Colors | Monochrome |
| Pixel Format | Rectangle |
| Signal Interface | Parallel Data (1ch, 4-bit) , 14 pins FPC |
| Power Supply | 5V (Typ.) |
| Active Area | 115.17(W)×86.37(H) mm |
HLM 8619 (TW-22 94V-0) Hosiden Summary
The HLM8619 ((TW-22 94V-0) is a 5.7 inch FSTN-LCD display panel from Hosiden Corporation (hereafter called Hosiden), it has an integral CCFL backlight system, without backlight inverter and without touch screen. It features an operating temperature range of 0 ~ 55°C , storage temperature range is about -20 ~ 60°C . Based on its features, Tsubis would recommend that this model be applied to Industrial line. Now this model is discontinued. If you want to use the HLM8619 (TW-22 94V-0) LCM in your future product, Tsubis GmbH recommend that you should contact with Hosiden or an agent to learn about the latest production and specification detail. The HLM8619 (TW-22 94V-0) production status marked on Tsubis.com is for reference only and should not be used as the basis for the user’s decision.. All specification details are inputted by Tsubis engineers according to datasheet, but we cannot guarantee the spec listed is correct.
